Wrangler/Gladiator Ultra 70/70 Axle Assembly - 40 Spline
Strongest front axle in the industry with our Military 2.5 Ton free wheel hubs.
On our website you can choose all the options such as locking, gear ratio, brackets and much more. check it out at www.knbaxles.com
Equipped with our housing Ultra 70 high or low pinion 70. Special design from innovative housing project where a 60 or 70 ring can be mounted, high pinion rear axle but with a reduced external size.
Front Axle high pinion 70
Axle is complete bolt-on with brackets and ABS.
Heavy Duty 3.5" diameter, 1/2" wall axle tubes.
KNB size 70 Knuckles
KNB 1.72" 40-spline SAE 4340 Chromoly axle shafts
KNB U-joints made of forged SAE 4340 chromoly with self lubricant bushing caps
F250/350 Lower Ball joints (same used top/bottom) available all around the USA.
KNB Forged Yoke shaft 1550
Free Wheel manual locking hubs 2.5 Ton 40 splines
Full steering hydro option
Vented rotor disc brake assemblies
8 lug (8 x 6.5" & 170) with double bolt pattern
Steel cover with magnetic bolt
Special triple seal to prevent water and clay from entering the axle
Heavy Duty 12.9" vented Rotors /4 Piston Disk brake assemblies
Spool, air locker or electric locker 70 available
Rear Axle high pinion or low pinion 70
Axle is complete bolt on with brackets and ABS
Full float axle Design
Heavy Duty 3.5" diameter, 0.43" wall axle tubes.
KNB 1.72" 40-spline SAE 4340 Chromoly axle shafts
Vented rotor disc brake assemblies
8 lug (8 x 6.5" & 170mm) double bolt pattern
Steel cover with magnetic bolt
Special triple seal to prevent water and clay from entering the axle
Heavy Duty 12.9" Rotors/2 Piston Disk brake assemblies
Spool, air locker or electric locker 70 available
